Complete 320Ah or 640Ah Off-Grid Heated Lithium & Dual-Source Charging Power Package

Sub-zero protected 4.1kWh or 8.2kWh LiFePO4 leisure storage combined with an IP68 waterproof 25A DC-DC and integrated MPPT solar charging system. Engineered for professional retrofit into electric campervans, Euro 6 smart alternator motorhomes, and traditional touring builds. Professionally fitted to BS 7671 and NCC standards at our Worcestershire workshop.

Supply Only or Fully Fitted at CCCAMPERS

Professional Workshop Installation

Installation duration can vary slightly depending on base vehicle architecture (EV auxiliary loop vs under-chassis diesel routing). Final fitting time confirmed upon booking.

Vehicle Platform Compatibility

⚡ Electric Vehicle (EV) Campervans

  • Regulated 25A Current Draw: Safely isolates and limits power draw to avoid overloading the vehicle's primary high-voltage to low-voltage DC-DC converter.
  • Intelligent Ignition Activation: Charges only when the vehicle is powered in "Drive" or "Ready" accessory mode.
  • Solar Harvest Priority: Automatically channels rooftop solar energy first to conserve drive battery capacity.
  • Shore Power / Hook-Up Compatible (2018+ Motorhomes): Most motorhomes manufactured from 2018 onwards are fitted with a factory 20A AC-to-DC mains converter — fully sufficient to charge the LiFePO4 battery bank via your existing hook-up connection. No additional charger required.

🚐 Diesel & Petrol Motorhomes

  • Smart Alternator Compatibility: Overcomes Euro 5/6 regenerative braking voltage drops to deliver a rock-solid, multi-stage charge.
  • IP68 Waterproof Sealed: Fully sealed enclosure permits under-chassis, external battery box, or wet locker mounting.
  • Heavy-Duty Quick Connects: Pre-fitted disconnect plugs enable rapid servicing and winter isolation.
  • Shore Power / Hook-Up Compatible (2018+ Motorhomes): Most motorhomes manufactured from 2018 onwards are fitted with a factory 20A AC-to-DC mains converter — fully sufficient to charge the LiFePO4 battery bank via your existing hook-up connection. No additional charger required.

Technical Specifications

Battery Storage Capacity 320Ah (~4,096Wh) or 640Ah (~8,192Wh) usable energy storage
Battery Chemistry & Heating LiFePO4 with built-in automatic thermal heating pads for safe sub-zero (<0°C) charging
Battery Management (BMS) Integrated internal BMS with over/under voltage, over-current, thermal cut-offs & wireless Bluetooth app telemetry
DC-DC Charge Current 25A continuous output (~350W power harvest from vehicle power rail / alternator)
Integrated Solar MPPT Input Up to 31V open-circuit voltage (Voc), harvesting up to 350W peak solar power
Operating Efficiency & Ingress 96% – 98% efficiency, IP68 100% waterproof sealed construction
Input Voltage Architecture 9V – 31V wide input range (works seamlessly on both 12V and 24V primary systems)
Mains / Shore Power Charging Compatible with factory-fitted 20A AC-to-DC converters on 2018+ motorhomes — no additional charger required
Regulatory & Safety Compliance BS 7671 (18th Edition), BS EN 1648-2, R10 Earth Bonded, 16A RCD, NCC Academy & AWS Certified

What's Included in the Complete Kit

  • 1x 12V 320Ah or 640Ah Heated LiFePO4 Lithium Leisure Battery (M8 terminal bolts included)
  • 1x 25A IP68 Waterproof DC-DC & MPPT Solar Charger with pre-wired heavy-duty quick disconnects
  • High-Current Cabling: 16mm² multi-strand tinned copper supply and earth leads (sized to installation runs)
  • Fused Circuit Protection: Heavy-duty MIDI fuse holders paired with 40A fuses for both input and output rails
  • Isolation & Distribution: 275A continuous rotary battery isolation switch and dual-pole insulated M8 busbars
  • Installation Sundries: Protective split conduit, heat-shrink tube lugs, fixings, and ignition trigger harness

❓ Frequently Asked Questions

Is a 320Ah or 640Ah heated lithium battery suitable for off-grid campervan use in winter? Yes. The built-in thermal heating pads activate automatically below 0°C, enabling safe charging in sub-zero conditions. The 320Ah (~4,096Wh) can power a 12V compressor fridge, diesel heater, and 230V appliances for multiple days without shore power. The 640Ah (~8,192Wh) doubles that capacity for true gas-free, grid-free living.
Does this lithium battery system work with electric vehicle (EV) campervans? Yes. The 25A DC-DC charger is specifically rated for EV and hybrid campervans. It safely limits current draw to avoid overloading the vehicle's HV-to-LV converter and only activates in Drive or Ready mode. CCCAMPERS are experienced in EV auxiliary electrical integration to IMI TechSafe Level 3 standards — making us the most qualified campervan converters in the UK for EV electrical work.
Do I need an additional charger if my motorhome already has a mains hook-up converter? No. Most motorhomes manufactured from 2018 onwards are fitted with a factory 20A AC-to-DC mains converter. This is fully sufficient to charge the LiFePO4 battery bank via your existing shore power or hook-up connection — no additional mains charger is required.
Where is this heated lithium battery system installed? All installations are carried out in-house at CCCAMPERS' dedicated conversion facility: Woodside Business Park, Beach Hay, Bayton, Kidderminster, Worcestershire, DY14 9NE. Our AWS-certified, NCC Academy-trained, and IMI TechSafe Level 3 technicians complete the full supply, wiring, and commissioning.
Is this lithium battery installation compliant with UK leisure vehicle electrical standards? Yes. Every installation is hardwired to BS 7671 (18th Edition) and BS EN 1648-2 standards, with R10 chassis earth bonding and a 16A RCD breaker. This maintains full UK leisure vehicle insurance validity and NCC compliance. CCCAMPERS hold Approved Workshop Scheme (AWS) accreditation and NCC Academy certification.

🏅 Why Choose CCCAMPERS for Your Lithium Upgrade?

  • IMI TechSafe Level 3 — the highest auto-electrical certification available in the UK
  • NCC Academy Certified — National Caravan Council approved training and standards
  • Approved Workshop Scheme (AWS) — independently accredited leisure vehicle workshop
  • BS 7671 (18th Edition) Wiring Regulations — every installation hardwired to current UK standards
  • BS EN 1648-2 Compliant — leisure vehicle low-voltage electrical systems standard
  • Dedicated Conversion Facility — Worcestershire, UK (DY14 9NE) — in-house, not subcontracted

Looking to Have This Fitted by Our Workshop Specialists?

Our Approved Workshop Scheme (AWS) technicians carry out complete supply, wiring, and commissioning at our Worcestershire facility. Book your fitting appointment or contact our team to discuss custom wiring requirements for your vehicle.

Average Fit Time: 2 Days | AWS Habitation Certified | IMI TechSafe Level 3
