Witley Kia PV5 Cargo Campervan Conversion

Motorhome comfort, thoughtfully fitted to your own electric van.

Turn your Kia PV5 Cargo into a welcoming place for weekends away and longer touring holidays. The Witley by CCCampers combines a rear kitchen, flexible twin or full-width sleeping arrangements and a Stargaze panoramic pop-top, bringing the comforts of life on board to quiet electric motoring.

Prepare supper after a day exploring, enjoy a leisurely breakfast or settle in for the evening. With a dedicated rear kitchen and a layout that adapts from daytime living to sleeping, the Witley makes room for the simple pleasures of being away.

Conversion prices start from £25,999. You supply the Kia PV5 Cargo; the base vehicle is not included. We design and fit your conversion at our workshop in Bayton, near Kidderminster, Worcestershire.

The standard specification requires factory-fitted 3.6 kW Vehicle-to-Load (V2L), a heat pump and the additional sliding door. We check your individual van, seating requirements and payload before agreeing the build.

Typical build time is 6–8 weeks from drop-off, with scheduling confirmed during consultation. A roof bed and mattress are optional extras. ISOFIX is not included in the Witley layout.

Book a Witley conversion consultation

Witley or Shelsley: which Kia PV5 layout suits you?

Choose the Witley for a Kia PV5 Cargo conversion with twin or full-width beds, a rear kitchen and a slide-out cassette toilet. ISOFIX is not included.

Choose the Shelsley for a classic side-kitchen layout in a suitable Kia PV5 Cargo or Passenger. Rear-seat ISOFIX mounting points are included in its standard specification, subject to the final approved seating configuration and child-seat compatibility.

Compare the Shelsley conversion

Final seating, compatibility and payload are confirmed against your individual vehicle. For wider platform and planning information, read our Kia PV5 campervan conversion guide.

Looking for a Kia PV5? Speak to our Kia PBV Centre contact

If you are sourcing a Kia PV5 for a CCCampers conversion, speak to Steve Herling at Brindley (West Bromwich) – PBV.

Address: Brindley (West Bromwich) – PBV, Tipton, DY4 7BX
Sales: 0121 826 1260

Ask for Steve Herling and quote “CCCAMPERS” to enquire about extra discounts. Ask Steve to confirm the current offer, any conditions and whether the quoted price already includes an applicable government grant.

Before ordering, send CCCampers the proposed vehicle’s factory specification so we can check its suitability for your chosen conversion: Witley with twin sliding doors or Shelsley with a single sliding door. Both require a factory-fitted heat pump and 3.6 kW Vehicle-to-Load.

Buying a new Kia PV5 Cargo: check the current van grant

If you intend to buy a brand-new Kia PV5 Cargo and supply it to CCCampers for conversion, ask the selling dealer about the government’s current zero-emission van grant before ordering.

The Kia PV5 Cargo is currently listed among eligible large vans, with a discount of 35% of the purchase price, capped at £5,000, subject to the scheme’s current conditions and availability.

The dealer or manufacturer handles the application and includes the grant as a discount in the vehicle purchase price. An advertised vehicle price may already include that discount.

The grant does not pay towards the CCCampers conversion. Do not assume that it applies to every PV5 variant, a used or demonstrator vehicle, or a complete campervan supplied or registered as a motorcaravan from new.

Ask the seller to confirm eligibility for the exact vehicle, its registration category and your proposed conversion before committing. Grant amounts, eligible models and availability can change.

Check the current GOV.UK electric van grant guidance and eligible vehicles.

Stargaze panoramic pop-top roof

The rear-opening Stargaze roof hinges at the front and raises at the rear, adding standing room and ventilation above the rear kitchen. Open the panoramic canvas when parked to enjoy the view and bring a little more of the outdoors into your campervan.

• Waterproof, durable, weather-tested marine-grade canvas.
• Panoramic canvas opening for views and ventilation.
• Standing room over the kitchen area.
• Designed for British touring conditions.

Included: Stargaze roof integration. Optional: roof bed and mattress, unless specifically included in your agreed specification. Close and secure the roof before travelling.

More energy for your time away

The Witley uses two electrical systems for different jobs. A separate 100Ah lithium leisure battery supplies the fridge, lights and USB charging. The Kia’s factory-fitted 3.6 kW V2L supply draws electricity from the much larger driving battery for compatible mains appliances, including the induction hob.

The 100Ah leisure battery is therefore not the main energy store for induction cooking. In the standard V2L arrangement, mains appliances draw on the driving battery without needing a separate leisure-battery inverter for that supply.

With the same mains appliances running, access to the Kia’s larger driving battery can provide substantially longer use than a conventional 320Ah leisure-battery and inverter setup. The advantage comes from the larger available energy reserve, not V2L alone.

Camping and driving share that reserve, so you must keep enough charge for your next journey. Available energy and running time depend on the vehicle’s battery specification, starting charge, appliance demand and V2L operating limits. The full driving-battery capacity should not be treated as available for camping.

The 3.6 kW figure describes the V2L supply’s power output, not how long it will last. The combined demand of appliances used together must remain within the limits of the supply and fitted electrical system.

Standard Witley conversion specification

Leisure power and gas-free cooking

• 100Ah LiFePO₄ lithium leisure battery for the fridge, lights and USB charging.
• 25A DC-to-DC charger for charging while driving.
• LiFePO₄ mains charger for campsite hook-up charging.
• 1,000W single induction hob, with a double-hob upgrade available.
• 7-inch touchscreen hub for system diagnostics and control.

Read the CCCampers Kia PV5 electric camper power guide

Required Kia factory equipment

The standard Witley conversion uses the Cargo’s factory-fitted heat pump, 3.6 kW V2L and additional sliding door. Confirm these before purchasing a base van or booking your conversion.

• 3.6 kW V2L: supplies compatible mains appliances from the driving battery without a separate inverter for this arrangement.
• Kia factory-fitted heat pump: provides space heating through the vehicle’s heating system.
• Additional factory-fitted sliding door: required for the standard Witley Cargo layout.

We explain the vehicle settings, parked operation and fitted electrical controls during handover. Heating and V2L use consume energy from the driving battery and must be considered alongside the range required for your journey.

If your Cargo lacks the heat pump or V2L, do not assume it meets the standard Witley requirements. We can discuss alternative equipment and assess suitability before agreeing a different specification.

Options to discuss include the Truma Varioheat Eezy 240V campsite heater and our Smart Lithium / UPS Inverter retrofit fitting service. These are alternative or additional equipment options, not the Kia factory heat pump, and require a vehicle-specific assessment.

Optional intelligent campsite power management

An intelligent grid-priority system can manage competing loads when connected to a campsite supply. For example, it can pause vehicle charging while a high-demand cooking appliance is operating and resume charging afterwards.

This is an optional upgrade, not included in the standard customer-supplied Witley conversion. The campsite connection rating and total appliance load must still be respected. Availability and compatibility are confirmed before ordering.

Comfort, storage and utilities

• 120W integrated underfloor heating, as listed for this conversion package.
• Three-stage insulation for sound and heat control.
• Framed curtains for privacy and thermal retention.
• Twin-bed seating and sleeping arrangement with a reinforced chassis fitting frame; applicable seating test evidence is confirmed for the installation.
• Infill arrangement for a full-width bed.
• Slide-out cassette toilet.
• Dimmable halo lighting.
• 50L dual-hinged fridge.
• 30L fresh-water tank with digital level gauges.
• Double USB charging points.
• Tailored wall, floor and furniture finishes.

The listed underfloor heating is separate from the Kia heat pump. Its supply requirements and operation are explained as part of your agreed specification and handover.

Exterior graphics and underbody protection

• Side graphics to complement your campervan’s exterior.
• Underseal applied to the underbody and exposed chassis components to help protect against road spray and corrosion.
• Tyre Protector puncture protection.

Dimensions and parking

The existing specification states a length of 4,695mm and a body width of 1,895mm, with widths of 2,255mm with mirrors out and 2,100mm with mirrors folded. The stated roof-closed height is 2,090mm.

Confirm your individual van’s dimensions and the finished conversion height, including accessories, before relying on these figures for parking bays, garages or height barriers.

Seating, sleeping and vehicle suitability

We confirm your seating arrangement, restraint requirements and available payload before agreeing the conversion. A payload example showing a particular number of people does not establish that the vehicle has that number of approved travelling positions.

ISOFIX is not included in the Witley layout. If ISOFIX is important to your plans, discuss the Shelsley’s seating options with us before choosing your vehicle.

A roof bed and mattress are optional extras. Any additional sleeping arrangement must be confirmed for your roof and conversion specification.

Payload: how much can your Witley carry?

These indicative examples use a Kia PV5 gross vehicle weight of 2,785kg, a Witley build adding approximately 295kg to standard kerb weight, 75kg per person and a fixed 20kg allowance for pots and pans. The 71.2 kWh battery adds a further 45kg in these examples.

Remaining payload is the total allowance for luggage, food, water and additional equipment, not a separate luggage allowance. Check the actual vehicle’s plated weight limits, kerb weight, loading basis and Stage 2 documentation where applicable. Confirm whether the driver and fluids are already included in the stated weights.

These are planning examples, not a guarantee for every van or an approved seating count. Use actual occupant weights and account for everything carried. Do not exceed the vehicle’s plated gross vehicle weight or individual axle limits.

Workshop expertise and build documentation

CCCampers combines IMI Level 3 TechSafe EV/hybrid training, NCC Academy Trained personnel and AWS Approved Workshop status.

The existing build specification references BS 7671 Section 721, the applicable parts of BS EN 1648, BS EN 1646-1, BS EN 721 and BS EN 13878. Seat and seat-belt anchorage requirements, including UN ECE R14 where applicable, depend on the actual installation and its supporting evidence.

Permanent safety ventilation remains important in a gas-free campervan. LPG installation requirements apply where LPG equipment is fitted; the standard Witley uses induction cooking rather than an LPG cooking installation.

We explain the documentation and inspection records relevant to your agreed build. Any vehicle approval evidence is specific to the vehicle and installation.

Optional upgrades and personalisation

Make the Witley your own with finishes and equipment chosen around your touring plans. Upgrade availability, compatibility and pricing are confirmed before ordering.

• Intelligent campsite power management upgrade.
• Furniture and worktop finishes.
• Interior lining colours and flooring colours.
• Pop-top canvas colours.
• Roof colour-coding options, subject to confirmation for your Kia PV5 Stargaze roof.
• Optional roof bed and mattress, subject to compatibility.
• Exterior styling options to discuss: alloy wheels, rear bumper protector, HEKO wind deflectors, Helix Ci3 speaker upgrade, gloss-black front splitter, side skirts, rear diffuser/splitter and roof bars.
• Onboard hot water and external shower point, with the exact heater and supply requirements confirmed before ordering.
• Truma Varioheat Eezy 240V campsite heater as an additional or alternative heater, subject to assessment.
• 12V Chillbeater heater, subject to assessment.
• 200W solar panel and MPPT.
• Kia PV5 Fiamma F45s wind-out awning.
• Matching front and rear seat upholstery.
• iTrack S7 GPS tracker.

Kit out your campervan kitchen

From the first brew of the morning to supper after a day exploring, the right accessories help make your campervan feel your own.

Browse campervan kitchen appliances and accessories.

These accessories are purchased separately unless expressly included in your order. Check each appliance’s power requirements against your fitted electrical system and the combined load of equipment used together.

Witley Kia PV5 conversion: frequently asked questions

Is the Kia PV5 included in the conversion price?

No. This is a conversion and fitting service for a suitable customer-supplied Kia PV5 Cargo. You provide the van; CCCampers carries out the conversion.

How much does the Witley conversion cost?

The conversion starts from £25,999. Stargaze roof integration and the listed standard conversion equipment are included. The base van is not included. Optional extras and the final specification are confirmed before ordering.

Can the Witley be fitted to a Kia PV5 Passenger?

No. This Witley conversion is for suitable Cargo models. Compare the Shelsley for Passenger conversion options, subject to the individual vehicle specification.

What factory equipment does the Witley need?

The standard specification requires the factory-fitted heat pump, 3.6 kW V2L and additional sliding door. Speak to us before choosing your van. If equipment is absent, any alternative arrangement must be assessed and agreed separately.

What is the 100Ah leisure battery used for?

The separate 100Ah lithium leisure battery supplies the fridge, lights and USB charging. Compatible mains appliances, including the induction hob, use the Kia’s factory-fitted V2L supply, which draws energy from the driving battery.

Can V2L run camping appliances for longer than a separate leisure battery and inverter?

With the same mains appliances running, access to the Kia’s larger driving battery can provide substantially longer use than a conventional 320Ah leisure-battery and inverter setup. Actual running time depends on starting charge, appliance use, V2L operating limits and the charge retained for driving.

What provides the space heating?

The standard conversion uses the Kia’s factory-fitted heat pump for space heating. The listed 120W underfloor heating is a separate fitted system. We explain the settings, supply requirements and operation during handover.

Is intelligent campsite power management included?

No. It is an optional upgrade on this customer-supplied Witley conversion. Availability and compatibility are confirmed before ordering. The campsite connection rating and total appliance load must still be respected.

Does the Witley include ISOFIX?

No. ISOFIX is not included in the Witley layout. Compare the Shelsley if ISOFIX matters to you, subject to the final approved seating configuration and child-seat compatibility.

Is a roof bed included?

No. Stargaze roof integration is included, but the roof bed and mattress are optional extras unless specifically included in your agreed order.

Is the Witley gas-free?

Yes. The standard conversion uses induction cooking and electrical equipment rather than an LPG installation for the living equipment. Any requested changes are reviewed as part of the final specification.

How long does the conversion take?

Typical build time is 6–8 weeks from drop-off. We confirm the schedule and agreed specification during consultation.

Where is the conversion fitted?

At the CCCampers workshop in Bayton, near Kidderminster, Worcestershire, DY14 9NE. Workshop visits are by appointment.

What training and workshop credentials does CCCampers have?

CCCampers combines IMI Level 3 TechSafe EV/hybrid training, NCC Academy Trained personnel and AWS Approved Workshop status, with specialist experience in electric campervan conversions.

Request the current Witley conversion specification

Contact us for the current specification and quotation for your customer-supplied Kia PV5 Cargo. We’ll confirm the factory equipment, layout, seating, payload assumptions, included equipment and optional extras for your particular van.

Your agreed quotation and order confirm the final specification. This conversion service is separate from the complete Witley motorhome, which includes a base vehicle.

Plan your Witley campervan

Tell us about your Kia PV5 Cargo and how you want to travel. We’ll check its factory equipment, discuss the sleeping arrangements and help you choose a specification that suits your plans.

Workshop: CCCampers Ltd, Units 3–5, Woodside Business Park, Beach Hay, Bayton, Kidderminster, Worcestershire, DY14 9NE, United Kingdom.

We welcome customers from Worcestershire, the West Midlands, Shropshire, Herefordshire, Gloucestershire, Wales and across the UK. Workshop visits are by appointment.

Book a Witley conversion consultation · Call 0333 456 3345 · Email sales@cccampers.co.uk
